M2M LTE CAT M/ NB-iot long life battery tracker for Vehicle/Asset Tracking

Dimensions:	96(L)x50(W)x11.2(H)mm
Manufacturer:	Eelink
Color:	Gray

GPT12-L is an NB-IOT/LTE-CAT M1 asset tracking Device which is dual LTE platform (NB-IOT/LTE-M) supporting long term, remote deployments without replace the battery. What's more, GPT12-L is very Easy to carry and easy to install, which can avoid more installation trouble than other tracking devices.

GPT12-L integrated a precision algorithm to charge and maximize the operating life of the Lithium Manganese Battery.

GPT12-L can be used not only for asset tracking, but also for vehicle tracking. The biggest advantage of GPT12-L is that it can accurately provide location data for longer periods. It has a standby time of up to three years. If you only need to know your vehicle and asset location once or twice a day and don't want to charge the device frequently, then the NB-IOT device will be your good chiose.

Inquiry Us + Sample Order

Description Features Specifications

If you are looking for the long life battery tracking devices with IoT network, and you have a requirement for the device with long standby properties, it is a good choice to buy NB-IOT devices GPT12-L.

NB-IOT deviceshas many advantages,learn more about NB-IOT devices from Eelink.

The new model GPT12-L is the result of building on live LTE CAT M1/NB-iot GPS tracking and connectivity. It provides a unique combination of enhanced coverage and long battery life, as well as reliable connectivity.

With a smart and thin design, GPT12-L is ideal for fleet management and Asset management, also can be used for many areas, such as car rental, mortgage, asset protection, M2M communication, automatic solutions for supply chain etc.

We will learn more about the features, applications and related parameters of GPT12-L.

Applications

Vehicle/fleet Tracking

Asset Tracking

Insurance Company

Financial Companies

Car Rental

Car Dealers

Mortgage

GPS tracker OEM/ODM

Customization

FAQS

Q：Positioned by GPS / LBS ?
A：GPS called“Global Positioning System”,GPS device can be positioned by GPS
satellite outdoor. Device also can be positioned by base stations of operator
which call LBS ,mainly for assistance positioning.
Q：Location is not accurate?
A：If need accurate positioning, use device outdoor where GPS signal is good and
start GPS tracking mode.
Device indoor mainly positioned by LBS, the accuracy lower than GPS
Q：Standby time can be longer?
A：Device need Internet connection. Standby time will be different by different using environment and working mode.

Q：Device offline?
A：The conditions below results in offline.
① No balance or No SIM ② No GSM or GSM signal is weak ③ Battery runs out

The Features of GPT12-L

1.GPS/Glonass/Beidou/Galileo/Qzss
Globally support various satellite positioning systems,cover all countries
2.Long Standby Mode
Default mode,work 3 mins per day
3.Emergency Mode
Start a period of real-time tracking
4.Flexible Solutions
Set the sleep/wake up time based on demand
5.Lithium Manganese Battery
Low self-discharge, longer standby time
6.GSM+LTE CAT(LTE-M)/NB-IOT(NB1)
More supported network in global
7.Smart & Thin
Easy to install and hidden in anywhere
8.GEO-Fence Alarm
Out of the set distance range, alert will be send
9.Remote Setting
Setting command Through server, App, SMS
10.Support Eelink Protocol 2.0
Open protocol.Customers can dock our protocol

Specifications of GPT12-L

Dimension：96(L)x50(W)x11.2(H)mm
Color：Gray
Switch：1 For Power on
Battery：4500 mAh
Weight：70g
Working Mode：Standby (Working 3 minutes per day, sleep in other time)
Emergency (Real-time tracking for 48 hours then sleep)
Current：LTE Cat M1(LTE-M) 124~265mA / NB-IOT(NB1) 65mA~78mA (Wake up); 10uA (Sleep)
Temperature/Humidity：-20℃~70℃/20%~80%RH
GPS Band：1575MHz
GSM Band：850/900/1800/1900MHz
LTE-M/NB-IOT：LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28
LTE TDD: B39(For LTE-M only)
Antenna：Built-in GSM/LTE-M/NB-IOT antenna, FPC GPS antenna
GPS Accuracy：5-15m (Depend GPS Signal)
LBS Accuracy：>200m (Depend Density of Base Stations)
GPRS：<3s, <15s, <60s
Hot/ware/cold fix time：<3s, <15s, <60s
